Parallel Shaft Helical Gearboxes
Add Power "AHG" series is specially developed for foot mounting and universal mounting parallel shaft helical gearbox for high output torques and longer service life.
Add Power "AHG" Series Helical gearboxes are ideal for a wide range of applications in various industry. Our range of Helical Gearboxes can be easily configured to industrial process parameters with its high range of gear transmission ratio.
"AHG" series helical gearbox casing is made from high grade C.I. casting, Internal gears and pinions are made from special alloy hardened steel.
Add Power "AHG" series Gearbox are available in more than 12 sizes and running up to 100 KW.
Specifications :
- Power : High power ratings for maximum torque from 0.25 KW to 500 KW and Up to 2500Nm
- Size : Available in 80 C.D to 280 C.D (C.D. = Centre Distance)
- Input : Hardened Solid shaft with keyway
- Output : Solid of Hollow shaft with keyway
- Modifications : Double input shaft and double output shaft also available
- Ratio : 6:1 to 90:1
- Lubrication : Splash oil type 320
- Other Features : FLS (Force Lubricating System) also available if required. Comes with Cooper water cooling pipe. Universal mounting position model also available
Application and Industries:
- Cranes
- Cement
- Mixers
- Plastic
- Steel and Foundry
- Road construction
- Sugar mill
- Port handling
- Chemical Plant
- Conveyors and Feeders
- Rubber Industry
- Paper Industry
- Power plants etc.
